regular traffic: velino [EN 115] 35°

The design escalator for stylish interiors.

The velino series escalators are reliable systems that operate at the highest level. Proven technologies, like the dual-circuit brake system - an optimum safeguard, ensure the highest degree of safety and a long service life. In addition, velino series products offer a wide array of design options. These are the best prerequisites for adding highlights without compromising the unique style of your shopping centre, multifunctional congress centre, or airport.

Show more

BASIC PRODUCT SPECS
Step width: 800mm | 1,000mm
Inclination: 35.0° ( 27.3° | 30.0° )
Rise max: 15m
Rise min: 2.5m
Max Rise w/o intermediate support: 6.0m @ 30° and 2 horizontal steps | 6.0m @ 35.0° | 6.10m @ 30°, 800mm step width and 3 horizontal steps | 5.50m @ 30°, 1000mm step width and 3 horizontal steps

BASIC DESIGN OPTIONS
Balustrades: Slim | Robust (Glass)
Handrail Colours: Black|Dark grey |Grey | Blue |Red| Brown|Beige|Green|Other colours on request.
BIM Lighting Options: Comb plate | Under handrail | Skirt band
ADD Lighting Options: Soffit | Truss | Multiple traffics light designs
Claddings: Standard options stainless steel: AISI 443/1.4521| AISI 441/1.4509 |AISI 304/1.4301|AISI 316/1.4404 . Powder Coated: RAL Range. Prime painted: RAL range | Customer specific solutions are available

ENERGY SAVING OPTIONS
Star Delta | Energy Efficiency Controller | Smart Frequency Converter | Stop&Go

Material main: Steel
Material secondary: Glass
Designed in: Germany
Manufactured in: Germany
BIMobject Category: Construction - Escalators
IFC classification: Transport Element
Code: L7722
Description: Escalators
Code: SS-80-40-25
Description: Escalator Systems
Uniclass 2015 Code: Ss_80_20_62_28
Uniclass 2015 Description: Escalator systems
Code: 80-40-25
Description: Escalator Systems
CSI MasterFormat 2014 Code: 14 31 00
CSI MasterFormat 2014 Title: Escalators
OmniClass Number: 23-23 11 13
OmniClass Title: Escalators
CSI UniFormat II Code: D1020
CSI UniFormat II Title: Escalators & Moving Walks

Category-Specific Properties

Construction - Escalators

Name Value
Application Office ; Residential ; Hospital ; Hotel ; Retail ; Commercial
Bulstrade Height 1000 ; 1100
Capacity 6750 ; 9000 l
Floor Material Stainless Steel
Inclination 35
Railing Color Black ; Dark grey ; Grey ; Blue ; Red ; Brown ; Beige ; Green ; Other colours on request
